Kemwell Boards for Fire Rated Floors and Ceilings

SAVING LIVES | PROTECTING BUILDINGS & CONTENTS | MAINTAINING VITAL SERVICES

A Fire Rated Board for Floors and Ceilings

A guide to suspended and self-supported fire rated floors and ceiling linings using FireKem FP-900® High Performance Calcium Silicate Board

Kemwell FireKem FP-900 ® is an easy-to-install, clean and lightweight, non-combustible calcium silicate fire protection building board.

It has multi-purpose applications and is commonly used for commercial and industrial building projects.

As a versatile Class 0 rated board, it is perfect for ceilings and floors as well as internal partitions, external walls, roofs, and drywall construction applications.

The inherent alkalinity of the board makes it anti-bacterial, meaning it is suitable for use in conditions where hygiene is of concern, such as in hospitals or food preparation areas.

It provides superior fire resistance performance and excellent dimensional stability under heat and severe moisture environments making it an ideal choice for a variety of projects.

You can specify Kemwell FireKem FP-900 with confidence for Ceilings and Floors.

Find this product on NBS Source.

What sizes are available?

Thickness
9, 12, 15, 20, 25mm

Sizes
2400 x 1200mm

Manufacturing Tolerances
Thickness: +/- 0.5mm for 9-12mm
Thickness: +/- 1mm for 15-20mm
Width: +/- 5mm
Length: +/- 5mm

Boards manufactured in accordance with:

  • ISO 9001:2008 Standard Quality Management Systems
  • ISO 14001:2004 Environmental Management Systems
  • Ceilings
  • Floors

Plus

  • Roofs
  • Cavity barriers
  • Partitions and external walls
  • Tunnel linings
  • Wind posts
  • Electrical and mechanical services enclosures
  • Smoke barriers
  • Fire doors
  • Industrial
  • Commercial buildings
  • High-rise construction
  • Health and leisure
  • Schools and educational
  • Restaurants and hotels
  • Residential properties
  • Infrastructure

FEATURES

Fire Resistance

FireKem FP-900® has superior fire resistance performance and the boards are approved for up to 240 minutes fire resistance according to BS 476: Part 22: 1987 depending on application.

Dimensional Stability

FireKem FP-900® has excellent dimensional stability under elevated temperatures and in severe moisture environments.

Moisture Resistant

FireKem FP-900® will not deteriorate when used in damp or humid conditions and will not encourage mould growth. The boards are also rot proof.

Performance characteristics are not degraded by age or moisture. Untreated surfaces will absorb water, which can cause some loss of strength, but full strength is regained after drying.

Chemical Stability

FireKem FP-900® is a chemically inert calcium silicate board, unaffected by contact with most chemicals and resistant to dilute acids and alkalis.

Acoustic Performance

FireKem FP-900® provides good acoustic reduction performance of between 26-49dB. It also provides thermal conductivity (approximately) at 20°C of 0.17 W/mK.

Easy Workability

No special equipment is required for cutting or drilling of FireKem FP-900® boards. It is recommended that cutting of the boards is carried out in well-ventilated situations, or the wearing of suitable dust masks to reduce the hazard of nuisance dust production, during the cutting or drilling process.

Boards may be flat head nailed or pilot drilled, then screwed.

Smooth Surface

FireKem FP-900® has a smooth surface but due to their high suction should be first sealed prior to applying paints, plasters, or wallpapers.

Durability

FireKem FP-900® is a lightweight but strong building board. System performance is unaffected by the hazards and condition of its working environment it does not rot.

Vermin Resistant

FireKem FP-900® boards remain unaffected by rodent, termite and insect attack.
